ETFE 4010
General-Purpose Fluoroplastics
Everflon™ ETFE 4010.
The versatile balance of flow and toughness.
A melt-processable modified copolymer of ethylene and tetrafluoroethylene. Engineered with an intermediate flow rate to deliver optimal processing speeds across extrusion, injection, and transfer molding.
7 g/10min
Intermediate Melt Flow (MFR)
150 °C / 302 °F
Continuous Service Temp
UL 94 V-0
Flame Rating
ASTM D3159
Type I, Grade 1 Standard
Balanced Performance
Engineered for high-rate versatility.
Everflon™ ETFE 4010 balances mechanical toughness, broad thermal capability, and efficient melt processing speeds for diversified industrial applications.
01
Intermediate Melt Flow
Nominal MFR of 7 g/10min enables higher throughput in extrusion, complex injection molding, and thin-wall component production.
02
Universal Chemical Inertness
Inert to almost all industrial chemicals, strong acids, bases, and solvents. Outstanding weather resistance and zero hydrolytic degradation.
03
Thermal & Impact Resilience
Continuous reliability up to 150 °C (302 °F) with excellent Izod impact strength (No Break) and cut-through resistance maintained across cryogenic ranges.
04
Stable Dielectric Performance
Low dielectric constant (2.5–2.6) and high dielectric strength (70 kV/mm) provide exceptional electrical insulation for connectors and wiring.
Technical Datasheet (TDS)
Everflon™ ETFE 4010 Property Data
Meets ASTM D3159 Type I, Grade 1
Processing & End Uses
Target Applications & Processing Guidelines
Engineered for balanced melt processing rates and multi-industry versatility.
■ Typical End Products
Electrical & Electronic Components: Sleeving, coil forms, sockets, multi-pin connectors, and switches.
Laboratory & Medical Ware: Chemical tubing, micro-valves, containers, and analytical dishes.
Battery & Instrumentation Parts: Structural components requiring chemical inertness and dimensional stability.
Chemical Service Hardware: Valve components, seal glands, pipe plugs, and corrugated tubing.
Industrial Films & Sheets: Extruded high-clarity release films and protective barriers.
■ Melt Processing Recommendations
Processing Techniques: Conventional melt extrusion, injection, compression, transfer, and blow molding.
Barrel & Melt Temperatures: Residence heating up to approximately 345 °C (650 °F). Long L/D barrels recommended.
Tool Metallurgy: Corrosion-resistant alloys (e.g., Hastelloy, Inconel) required in contact with molten resin.
Viscosity Behavior: Melt viscosity decreases with shear rate, permitting narrow die pressure extrusion.
Machine Selection: Reciprocating screw injection machines preferred for uniform plastification.
Quality Assurance & Standards
Certified quality. Global compliance.
Every production lot of Everflon™ ETFE 4010 undergoes rigorous quality control to meet strict North American industrial benchmarks and safety requirements.
✓
Industry Certifications
ASTM D3159 Standard Compliance
Meets ASTM D3159 Type I, Grade 1 specifications for intermediate-flow ETFE fluoroplastics.
UL 94 Flammability Standard
Certified V-0 self-extinguishing rating for critical aerospace and electrical applications.
IEEE 383 Radiation Benchmark
High-energy radiation resistance approved for nuclear power plant and aerospace use.
RoHS & REACH SVHC Compliant
Free of restricted heavy metals and hazardous substances, fully documented for US supply chain audits.
📦
Packaging & Handling
Standard Net Weight Package
Packaged in translucent, 2.5-mm (0.1-in) uniform pellets within 20.3-kg (45-lb) moisture-sealed plastic bags.
Palletized Logistics (US Standard)
50 bags per standard wooden pallet (1,015 kg / 2,250 lbs net), shrink-wrapped with moisture-barrier covering for shipping.
Indefinite Storage Stability
Resin properties are unaffected by storage time. Store in clean, dry ambient conditions to avoid airborne contamination and water condensation.
Lot Traceability & Documentation
Unique barcode and lot tracking on each bag linked to complete Certificate of Analysis (CoA) and Safety Data Sheets (SDS).
Quality Assurance: All property data is verified per ASTM standard test methods. Full lot-specific CoA provided with each shipment.
ISO 9001:2015 REGISTERED QUALITY SYSTEM
