PFA Color Concentrate
Engineered with virgin ultra-pure Perfluoroalkoxy (PFA) carrier resins and high-crystallinity inorganic pigments. Designed for semiconductor wet-process lines, deep downhole cable jackets, and mission-critical aerospace wiring up to 420°C.
Formulated exclusively with 100% virgin PFA carrier resins and crystalline, calcined inorganic spinels to ensure zero off-gassing, exceptional flex life, and pinhole-free extrusion.
Engineered to retain pigment saturation and full fluoropolymer mechanical strength without charring, color drift, or polymer degradation during intense high-drawdown melt processing.
Concentrated sub-micron pigment loads deliver full opacity with only 3% to 4% addition, minimizing compound procurement overhead while preserving parent resin properties.
Ultra-pure formulation guarantees negligible metallic ion extraction (ppb levels) in contact with hot hydrofluoric acid, SC-1, SC-2, and UPW process loops.
Available across tailored MFR grades to perfectly match standard compression molding, high-speed cable coating, and precision thin-wall medical tubing without flow lines or die accumulation.
Tested in accordance with MIL-STD-104 Class 1 & 2 and EIA-359-A color limits, supporting precision custom Pantone & RAL spectrophotometer matching.
High-purity furnace black, UV impervious
Thermally stable complex titanates
Vibrant non-degrading high-heat red
High-visibility EV & industrial cable
Heavy-metal-free calcined titanate
Cobalt titanate high-clarity green
Cobalt aluminate blue (420°C stable)
Consistent hue for paired harness wires
Neutral jacket and tubing colorant
Ultra-pure rutile titanium dioxide
Qualified across US and global high-tech semiconductor fabs, defense aviation programs, downhole energy exploration, and surgical device manufacturers.
Colored PFA tubing and valve manifolds for hazardous chemical distribution (HF, sulfuric acid, UPW). Guarantees zero ionic leaching and chemical inertness.
Complies with AS22759 wire construction specs. Provides lightweight, high-temperature (260°C rated) insulation with exceptional resistance to cut-through and engine fluids.
Withstands extreme downhole pressure, H2S exposure, and continuous steam environments without mechanical degradation or color fading.
Formulated with heavy-metal-free pigments compliant with FDA 21 CFR 177.1550 and USP Class VI standards for biocompatible surgical instruments.
Our PFA Color Masterbatch Portfolio
| Standard Color Matching | Available in MIL and RAL shades |
| Concentration Range | From 2% up to 10% to suit your product's wall thickness and color density needs. |
| Color Difference | ≤1.5 |
| Moisture Content | ≤0.03% |
| Particle Size | 1.3-2.1 mm |
| Dark Spot | ≤1% |
| Various MFR Options | Masterbatches are tuned to match a range of PFA melt flow requirements for injection, extrusion or film processing. |
| Full Compliance | RoHS and REACH compliant and free of heavy metals as your requirement. |
| Features | High thermal tolerance: Formulated to withstand typical PFA processing (melting/processing temperatures near ~260–280 °C) without colorant degradation; Preserved chemical resistance: Designed to maintain PFA's resistance to acids, bases and organic solvents; Electrical integrity: Compatible formulations that do not undermine PFA's superior insulating properties — suitable for high-performance wire & cable uses; Durability: Colorfastness and long-term stability in demanding environments (chemical exposure, thermal cycling, sterilization where applicable). |
| Applications | Wire & cable jacketing and insulation (especially where high temperature and electrical performance are required); Tubing, fittings and linings for aggressive chemical and thermal environments; Films and sheets for protective or insulating layers; Injection-molded parts for electronics, aerospace and medical components where PFA's properties are needed plus color or added functionality |
Color, meets extreme.
Explore the spec sheets. The future is ready.
Say Hello to Good Buy
Magichromatic
Space Black
Tangy Blue
Citrusy Orange
Neon Fuchsia
Lebanese Red
Yellow Buttercup
Snow White
INQUIRY
