PTFE MICROPOWDER MV3
Get to Know PTFE Micropowder MV3
Everflon™ PTFE MV3 fluoroadditive is a white, free-flowing, PTFE powder designed for use as an additive in other materials or as a dry lubricant. It can be used at temperatures from –190 °C to 250 °C (–310 °F to 480 °F), and is inert to nearly all industrial chemicals and solvents. It is a good electrical insulator, does not absorb water, and is highly resistant to weathering.
Typical Applications
It can be added at up to 30% by weight to base elastomers to improve abrasion resistance and lower the coefficient of friction. At 1-3% by weight, it is an excellent slip enhancer for a variety of water and solvent based inks. It can also be added to plastics, such as polyacetals,polyamides, polycarbonates, polyesters, polyimides, polysulfides, and polysulfones, at 5-20% by weight to reduce friction and wear.
Processing Guide
Heating Everflon™ PTFE in excess of 399 °C (750 °F) can produce toxic fumes. It is, therefore, necessary to provide local exhaust ventilation in areas where Everflon™ PTFE products are exposed to high temperatures. Avoid breathing fumes or contaminating smoking tobacco with fumes, powder, or dust.
Thermal decomposition of this product will generate hydrogen fluoride, which is corrosive. Corrosion resistant materials are required for prolonged contact with molten resin.
Precaution
Equipment used to process at melt temperatures should be provided with local exhaust ventilation (LEV) to completely remove all fumes and vapors from the processing area. In addition, care should be exercised to avoid the contamination of cigarettes and other forms of smoking tobacco when using fluoroplastic resins. Before processing any fluoroplastics, read the Material Safety Data Sheet.
Handing & Package
Everflon™ PTFE MV3 is packaged in 25-kg (55.1-lb) drums. Eight 25-kg drums are packaged on one pallet for ease of shipping, handling, and storage.
Data List
| Property | Test Method | Unit | Typical Value |
| Bulk Density | ASTM D-4894 | grams/liter | 440 |
| Particle Size – Low Shear | Laser Diffraction | Average (μm) D10 D90 | 3 18 70 |
| Particle Size | Hegman ASTM D-1210 | microns | 3 |
| Surface Area | Krypton adsorption | meter²/gram | 1.5~3 |
| Moisture Content | ASTM D-4019 | % | <0.1 |
| Particle Type | Rounded shape, intermediate hardness | ||
| Melting Point | ASTM D-3417 | °C (°F) | 325 (617) |
