Aqueous Liquid FEP • Melt-Flow Low Porosity • Non-Stick & Corrosion Resistant

Everflon™ Techyours™
FEP Water-Based Series

Advanced water-based FEP liquid topcoats designed to provide exceptional non-stick release, chemical resistance, and corrosion protection. FEP melt-flows to form extremely low-porosity films for superior performance.

Melt-Flow Low Porosity

FEP melt-flows during baking to form an exceptionally dense film of very low porosity, making it ideal for low-abrasion release applications.

Corrosion & Chemical Barrier

Pigmented layers applied as mid-coats further improve permeation resistance across the entire multi-layer coating system.

Precise Film Build (Max 12 µm)

Recommended dry film thickness up to 12 µm (0.5 mil) per coat, with a minimum of two coats recommended for optimal barrier performance.

FDA & EU Food Contact

Grades like 460-300 and 460-303 comply with US FDA and EU Regulation (EC) No 1935/2004 when paired with compliant primer systems.

Water-Based FEP Grade Portfolio

Everflon™ Techyours™ FEP 460 Series Product Line

Aqueous FEP liquid topcoats engineered for melt-flow low porosity and superior corrosion barriers.

Grade 460-300 (Clear Topcoat) Max 12 µm / Coat

Clear Aqueous FEP Topcoat

Transparent FEP liquid topcoat with viscosity of 500–1000 cps and volume solids of 27.6–28.6%. Delivers optimal release properties and low abrasion. FDA compliant.

Key Targets: Low-abrasion release applications, food contact rollers, molds.

Grade 460-303 (Black RAL 9004) Max 12 µm / Coat

Pigmented Black FEP Top/Mid-Coat

Pigmented black (RAL 9004) FEP aqueous coating with viscosity of 700–1100 cps. Functions exceptionally as a mid-coat to dramatically improve permeation resistance. FDA compliant.

Key Targets: Multi-layer corrosion barrier systems, industrial tanks, chemical piping.

Grade 460-304 (Green RAL 6017) Max 12 µm / Coat

Pigmented Green FEP Industrial Coat

Pigmented green (RAL 6017) FEP coating with viscosity of 300–800 cps. Engineered for high corrosion resistance in industrial chemical containment (Note: Not FDA compliant).

Key Targets: Non-food chemical processing equipment, corrosion-resistant hardware.

High-Coverage Water-Based FEP Efficiency

Theoretical coverage reaches up to 8.45 m²/kg (458 ft²/gal) at 25 µm (1.0 mil) DFT for Grade 460-300, delivering high economy per square meter.

Up to 8.45 m² / kg Coverage

Aqueous Rheology & Melt-Flow Science

Homogeneous Suspension & Low-Porosity Sintering

Advanced aqueous stabilization ensures smooth atomization and dense melt-flow film consolidation during baking.

Axial Flow Impeller Mixing

Gently mix for 15 minutes or more using an axial flow impeller until contents are homogeneous. Adjust mixer speed so that a vortex appears while avoiding air entrapment. Insufficient mixing leads to application defects.

• Prevents settling and ensures defect-free films

200-Mesh Precision Filtration

Filter through a 200 mesh (approx. 75 µm) stainless steel or nylon screen before spraying to remove micro-agglomerates and maintain seamless flow through fine fluid tips.

• Guarantees flawless surface finish

Aqueous Clean-Up & Deionised Water

Equipment clean-up is effortlessly performed using water. Use deionised water as thinner or additive when adjusting application parameters.

• Eco-friendly water-based flushing

Engineering Datasheet (TDS)

Physical Constants & Specifications (460 Series)

Physical constants are averages only and may vary up to 25%.

Water-Based FEP Properties Comparison

Property	460-300	460-303	460-304
Color	Clear	Black	Green
Closest RAL	-	9004	6017
Coverage m²/kg (ft²/gal)	8.45 (458)	7.99 (422)	7.74 (428)
Viscosity (cps)	500-1000	700-1100	300-800
Volume Solids %	27.6-28.6	25.4-26.4	25.7-26.7
Density kg/l (lbs/gal)	1.329 (11.1)	1.295 (10.8)	1.356 (11.4)
Max In-Use Temp	205 °C (400 °F)

Cured Film Performance & Operating Parameters

Recommended DFT	Max 12 µm (0.5 mil) per coat (min 2 coats)
Drying (Metal Temp)	10-15 min at 105-150 °C (220-300 °F)
Curing (Metal Temp)	20 minutes at 380-390 °C (720-730 °F) after each coat
Additional Long Bake	Up to 90 min at 330-340 °C (620-640 °F) for enhanced adhesion & abrasion resistance
Dielectric Breakdown Strength	> 50 kV / mm
Surface Tension / Non-Stick	18-20 dynes/cm (Low Energy Release)
Clean-Up Solvent	Water
Recommended Primers	420-7xx, 460-6xx, or 460-2xx series

Applicator Shop Floor Standard

Application Method, Drying & Curing Schedules

Precision liquid spray parameters for aqueous FEP topcoats.

STEP 01

Coating Preparation & Mixing

Gently mix 15 minutes or more until homogeneous using an axial flow impeller. Filter through 200 mesh (approx. 75 µm) stainless steel or nylon screen.

STEP 02

RP / Conventional / HVLP Spray

Use RP (Reduced Pressure), conventional, or HVLP gun. Nozzle: 0.8–1.2 mm. Atomizing air pressure: 2–3 bar (30–45 psi). Max 12 µm DFT per coat (min 2 coats).

STEP 03

Drying Flash-Off

Dry coating for 10–15 min at 105–150 °C (220–300 °F) metal temperature to evaporate water completely.

STEP 04

Curing & Long Bake

Cure 20 minutes at 380–390 °C (720–730 °F) after each coat. Optional long bake (up to 90 min at 330–340 °C) enhances inter-coat adhesion and corrosion resistance.

Recommended Spray Setup & Parameters (460 Series)

Gun Type: RP / HVLP / Conventional

Fluid Nozzle: 0.8 – 1.2 mm

Atomizing Air Pressure: 2 – 3 bar (30–45 psi)

Filtration Screen: 200 Mesh (~75 µm)

Equipment Clean-Up: Water

Industrial Deployment

Engineered for Low-Porosity Release & Corrosion Protection

Trusted worldwide in low-abrasion release mechanisms, chemical tanks, and anti-corrosion barrier systems.

🛡️

Corrosion Barrier Systems

Using pigmented FEP grades (like 460-303 and 460-304) as mid-coats drastically improves permeation resistance and protects chemical processing equipment.

🔄

Low-Abrasion Release Rolls

Melt-flow FEP films form very low porosity surfaces, making them the natural choice for non-stick release applications with minimal mechanical wear.

🧪

Chemical Handling & Food Tanks

FDA-compliant clear (460-300) and black (460-303) topcoats provide exceptional chemical inertia for food contact and industrial vessels.

Storage & Aqueous Shelf Life

Gently mix (15 min at 30 RPM) before use. Shelf life is 12 months at optimal storage conditions: 18 °C–27 °C (65 °F–80 °F). Maximum storage temperature 40 °C (105 °F).

• Water-Based Dispersion: Protect from freezing (Transport 5 °C–40 °C)

• Gentle Agitation Required Prior to Spray Application

Ensure containers are securely sealed after use to prevent skinning and evaporation losses.

Regulatory Compliance & Food Contact

US FDA Food Contact

Grades 460-300 & 303 comply with US FDA rules (460-304 is NOT compliant)

EU Regulation 1935/2004

Meets EU requirements for materials intended to come into contact with food

GMP Compliance

Manufactured under Good Manufacturing Practices Regulation (EC) n° 2023/2006

ISO 9001:2015

Strict batch consistency and quality management systems
