PTFE MICROPOWDER MV1
Get to Know PTFE MV1
Everflon™ PTFE MV1 is a white finely divided PTFE (polytetrafluoroethylene) micropowder which is easy to disperse in a wide range of liquids. Everflon™ PTFE MV1 is particularly suitable for use in surface coatings, metal decorating inks, low viscosity lubricating oils and is readily dispersed in liquids using either high or low shear mixing. This combination of properties makes Everflon™ PTFE MV1 very useful in coating formulations. Everflon™ PTFE MV1 is suitable for use in food contact applications. No perfluorooctanoic acid (PFOA) or its salts are used to manufacture Everflon™ PTFE MV1 .
Typical Applications
Everflon™ PTFE MV1 is used as an additive (at approximately 1–3% by weight) in the preparation of offset, gravure, and flexographic printing inks. It improves certain properties, such as rub and slip resistance. It is used in combination with polyethylene waxes to obtain the desired degree of property modification. Due to its small particle size and narrow particle size distribution, Everflon™ PTFE MV1 has been found useful in a variety of coating systems. Typical loadings of 5–20% by weight are used in plastics and elastomers.
Processing Guide
Heating Everflon™ PTFE in excess of 399 °C (750 °F) can produce toxic fumes. It is, therefore, necessary to provide local exhaust ventilation in areas where Everflon™ PTFE products are exposed to high temperatures. Avoid breathing fumes or contaminating smoking tobacco with fumes, powder, or dust.
Thermal decomposition of this product will generate hydrogen fluoride, which is corrosive. Corrosion resistant materials are required for prolonged contact with molten resin.
Precaution
Equipment used to process at melt temperatures should be provided with local exhaust ventilation (LEV) to completely remove all fumes and vapors from the processing area. In addition, care should be exercised to avoid the contamination of cigarettes and other forms of smoking tobacco when using fluoroplastic resins. Before processing any fluoroplastics, read the Material Safety Data Sheet.
Data List
| Property | Test Method | Unit | Typical Value |
| Bulk Density | ASTM D-4894 | grams/liter | 440 |
| Particle Size – Low Shear | Laser Diffraction | Average (μm) D10 D90 | 1.5 6 15 |
| Particle Size | Hegman ASTM D-1210 | microns | 1 |
| Surface Area | Krypton adsorption | meter²/gram | 2 |
| Moisture Content | ASTM D-4019 | % | <0.1 |
| Particle Type | Rounded shape, intermediate hardness | ||
| Melting Point | ASTM D-3417 | °C (°F) | 325 (617) |
Handing & Package
Everflon™ PTFE MV1 is packaged in 25-kg (55.1-lb) drums. Eight 25-kg drums are packaged on one pallet for ease of shipping, handling, and storage.
